5T@13.5M Stiff Boom Crane
Product description
This kind of stiff boom crane is designed for general cargo handling and service onboard ships and offshore units. The cranes are available in various range and can be supplied according to customer requirements. The stiff boom cranes can be delivered within a broad range of certifications and numerous optional features.
The boom type is straight, are typically used in dock, on fixed installations and in harbor conditions with its stability. OUCO Marine/Offshore Stiff boom cranes are with low cost, easy operation and high efficiency on different working conditions.
In certain situations a stiff boom crane even has a superior ability to reach over obstructions such as fences or walls where other cranes may fail.
Typical Applications: Service cranes, Hose handling cranes, Empty container and cargo handling cranes.
SB series crane: End User Advantages：
1. Compact design.
2. Small footprint.
3. Delivered as one complete unit ready for installation to vessels.
4. Easy access for periodic maintenance, service and repair.
5.24 hours after sales service support.
GA drawing
Product information
| 1 | SWL | 5T@13.5M |
| 2 | Max. Working radius | 13.5m |
| 3 | Min. Working radius | 3m |
| 4 | Hoisting speed | 0~10m/min |
| 5 | Hoisting height | 25m |
| 6 | Slewing speed | ~0.8r/min |
| 7 | Slewing angle | 360º |
| 8 | Luffing time | 45s |
| 9 | Working condition | TRIM≦2º |
| HEEL≦5º |
| 10 | Power | 30kw |
| 11 | Protect class | IP56 |
| 12 | Working type | S1 |
Production process
Company Information
Company Information
OUCO Industry, was established in February 1984, covers an area of 48,000 square meters, construction area is 35,000 square meters.
OUCO headquartered in crane hometown of Jiangsu Province where representing most advanced machinery manufacturing level in China.
OUCO has more than 150 employees, 20 were technical staff. Among that has five senior titles, 10 mid-level titles, and a total of 50 welder (who has got CCS, ABS and other main institutions’ certification). It also has professional organization certificated flaw detection staff, the quality system audit staff, and inspection personnel, etc.
FAQ
1.Q:What's the information should I provide when inquiry?
A: More details or drawings, better.
a: Lift capacity b: span c: lift height d: power sourceor other specials you give us will be more appreciated.
2.Q: How many operating methods for my selection?
A:Standard operating methodsr:
a: pendent controller with push buttons. b: remote control with push buttons
c: cabin(space capsule seat) control with joystick. Choose any type as you like.
3. Q:Can this type work in hazardous environment? A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.4. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, etc as your requirement!
5. Q:How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training.
6. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
