• Product Description

    OUCO manufactures small service cranes in different boom lengths and depending on the crane’s application, we offer certification by all major classification societies and a broad set of available accessories. They are designed and manufactured in conformity with the current Marine Rules and they can be customized on request.

    marine crane 1.jpg

    Product Feature

    Simple design simplifies the maintenance.

    Compliance with the most demanding safety rules and regulations;

    Overload protection;

    Reliable long service life guaranteed through the use of high quality reputable components, extensive endurance testing and easy future upgrades.


    Technical specification

    SWL0.35T3.5M
    Max. Working radius3.5m
    Min. Working radius1.5m
    Hoisting speed0~15m/min
    Hoisting height10m
    Slewing speed~0.8r/min
    Slewing angle360º
    Luffing time~40s
    Extension time~25s
    Working conditionTRIM≦2º
    HEEL≦5º
    Power4.5kw
    Working typeS1
    Genernal Arrangement


    20200106114043807.png@!w1200

    Production Process

    TB marine crane7501.jpg

    TB marine crane7502.jpg

    Company Information



Next:No More

share to:

0.35T@3.5M Yacht Marine Crane
SWL 0.35T@3.5M
MAX WORKING RADIUS 3.5m
MIN WORKING RADIUS 1.5m
HOISTING SPEED 0~15m/min
HOISTING HEIGHT 10m
SLEWING SPEED ~0.8r/min
SLEWING ANGLE 360°
LUFFING TIME ~ 40s
EXTENSION TIME ~25s
WORKING CONDITION
TRIM ≤2°
HEEL ≤5°
POWER 4.5kw
PROTECT CLASS IP44
INSUKATE CLASS F
WORKING TYPE S1
Small Yacht Marine Crane in Service
