• Product Description

    OUCO manufactures telescopic cranes in different boom lengths and depending on the crane’s application, we offer certification by all major classification societies and a broad set of available accessories. They are designed and manufactured in conformity with the current Marine Rules and they can be customized on request.

    Yacht Deck 1.jpg


    Product Feature

    Compliance with the most demanding safety rules and regulations;

    Overload protection;

    Reliable long service life guaranteed through the use of high quality reputable components, extensive endurance testing and easy future upgrades.


    Technical specification

    SWL1T@6M
    Max. Working radius6m
    Min. Working radius2.5m
    Hoisting speed0~12m/min
    Hoisting height15m
    Slewing speed~0.6r/min
    Slewing angle360º
    Luffing time~20s
    Extension time~25s
    Working conditionTRIM≦2º
    HEEL≦5º
    Elec motor powerY132ML-4-H
    Power4.5kw
    Power resourceAC380V/50HZ
    Working typeS1

    Genernal Arrangement


    Production Process

    TB marine crane7501.jpg

    TB marine crane7502.jpg

    Company information




    Packing & Shipping


share to:

1T@6M Yacht Crane
SWL 1t@6m
MAX WORKING RADIUS 6m
MIN WORKING RADIUS 2.5m
HOISTING SPEED 0~12m/min
HOISTING HEIGHT 15m
SLEWING SPEED ~0.6r/min
SLEWING ANGLE 360°
LUFFING TIME ~ 20s
EXTENSION TIME ~25s
WORKING CONDITION
TRIM ≤2°
HEEL ≤5°
ELEC-MOTOR POWER Y132ML-4-H
POWER 4.5kw
Speed 1450r/min
POWER RESOURCE AC380V/50HZ
PROTECT CLASS IP44
INSUKATE CLASS F
WORKING TYPE S1
